Ubiquiti UA-G3-Flex UniFi Access G3 Flex Reader (Black)

Black

84 x 84 x 40.8 mm
(3.3 x 3.3 x 1.6")

Yes

Yes

Yes

Yes

Yes

Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I

IP55

165 g (5.8 oz)

Polycarbonate, glass, aluminium alloy

Polycarbonate, aluminium alloy

Wall (Included)
Gang-box, junction box (Optional)

Yes

-30 to 60° C
(-22 to 140° F)

5 to 90% noncondensing

(1) 10/100 MbE RJ45 port

BLE 4.1
NFC

PoE
UL 294 Power-limited Class 2 PSU
UL 60950-1/62368-1 LPS/PS2 PSU

5W

44—57V DC

Air: ±15kV, contact: ±8kV

(12) Capacitive buttons

Yes (1x 1W)

R/G/B/W

(1) Factory-reset

13.56 MHz

< 30 mm (1.18'')

ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)
MIFARE Classic / MIFARE DESFIRE
Sony FeliCa™ (ID only)
NFC Forum tags T1T, T2T, T3T, T4T and T5T
ECP 2.0

Cat 5e cabling is the minimum performance category recommended. The performance category utilised should match the transmission speed required at the installation site.
The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.

Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.

Grade assignment: I

CE, FCC, IC, UL 294, CAN/ULC-60839-11-1

UA-G3-Flex V01

Access

The software version can be checked at https://unifi.ui.com
